Seeing the Unseen:Advanced Optical Solutions for Environmental Monitoring
Environmental monitoring is essential for understanding and protecting our planet. By utilizing sophisticated optical technologies such as FTIR and LIDAR, alongside optical filters, diffraction gratings, optical coatings, mirrors, and lenses, we can capture detailed data that informs critical decisions about our environment.
FTIR: Infrared Insights
Fourier Transform Infrared Spectroscopy (FTIR) is a powerful tool in environmental monitoring. By analyzing the infrared absorption of various substances, FTIR can identify and quantify gases, liquids, and solids in the environment. This technology is particularly useful for monitoring air quality, detecting pollutants, and analyzing soil and water samples. FTIR provides comprehensive insights into environmental composition, helping to detect even trace amounts of contaminants.
Omega Optical specializes in components for FTIR, such as Potassium Bromide (KBr), Cesium Iodide (CsI), Zinc Sulfide (ZnS), and Zinc Selenide (ZnSe) windows, beamsplitters, and the specialty coatings which enhance and protect these specialty crystals.
LIDAR: Mapping the Environment
Light Detection and Ranging (LIDAR) uses laser pulses to create detailed 3D maps of the environment. In environmental monitoring, LIDAR is used to measure vegetation density, map terrain, and monitor changes in land use and land cover. This technology provides precise, high-resolution data that is essential for understanding environmental dynamics and making informed conservation and management decisions.
Optical Filters: Clarity and Precision
Optical filters are vital in environmental monitoring systems, selectively transmitting specific wavelengths to isolate and analyze different components of the environment. These filters are crucial for applications like air and water quality monitoring, where precise identification of pollutants is necessary. By using high-quality optical filters, we can ensure clear and accurate data collection, providing essential insights into environmental conditions.
Diffraction Gratings: Detailed Spectral Analysis
Diffraction gratings disperse light into its component wavelengths, enabling detailed spectral analysis. In environmental monitoring, this is used to analyze the composition of air, water, and soil. By capturing the spectral signatures of various substances, diffraction gratings help identify and quantify pollutants and other environmental factors with high precision. This detailed analysis is crucial for understanding and mitigating environmental impacts.
Optical Coatings: Enhanced Performance
Optical coatings on lenses, mirrors, and filters improve their performance by increasing light transmission and reducing reflections. In environmental monitoring, these coatings ensure that imaging systems capture high-quality, accurate data even in challenging conditions. Coatings also protect optical components from environmental wear and tear, enhancing their durability and reliability over time.
Mirrors and Lenses: Directing and Focusing Light
Mirrors and lenses are integral to optical systems, directing and focusing light to capture detailed images and spectral data. High-quality lenses ensure precise light focusing, while mirrors accurately direct light paths within the system. These components are essential for capturing high-resolution data, enabling detailed analysis of environmental conditions and changes.
Explore the Features
Full Optical Capabilities
Learn more about the full suite of capabilities which are trusted by leading Global OEM’s and their Start-up challengers to deliver the right photons, to the right place, at the right time.
considerations for remote Monitoring
Illumination
Since the sun is typically used as the illumination source, the intensity can vary with cloud cover. Clouds, haze, and dust also influence the spectral distribution of the solar spectrum, preferentially scattering the lower wavelengths (Bartlett, et al., J. Geophys. Res. 103:31017, 1998). While the spectral variations are not a major contributor to errors, the system should be calibrated with a neutral (i.e. white) reflecting test target for the best measurements. This calibration step is common in satellite-based mapping applications.
Signal Source
Common pigments in plants include the dominant chlorophylls A and B which impart the green color, but also include a family of carotenoids and anthocyanins in differing amounts. The reflectance spectrum dips where absorption occurs.
- Reflectance signal- a combination of hydration, chlorophyll content and other pigment content (anthocyanines and carotenoids) influence the spectral dependence of the reflectance. Sunlight is used as the illumination source. Carotenoids and anthocyanins are upregulated and chlorophylls are downregulated during stress, turning the crops yellow and brown. This shows up in the reflectance spectrum and vegetation indices described below.
- Thermography can be used to make a temperature-map of the crop in the 9-14 micron wavelength range. Plants with good hydration and transpiration are cooler than those that are dry and heat-stressed. Sunlight is not strictly necessary to do this measurement, but it can be done at the same time as reflectance because IR wavelengths are detected.
Flight Height
This determines the field-of-view and resolution of the images. The height and field-of-view also determine the angles-of-incidence that hit the filter you are using for imaging. Filter response typically shifts to lower wavelengths and the edges become less steep as the angle-of-incidence increases. Learn more about how angle-of-incidence affects filter performance.
Spectral Filters
Typically bandpass filters that correspond to blue, green, red, red edge and NIR are used for normalized difference, red edge (NDRE) mapping. Some examples are below. Another option is to use linear variable bandpass filters which have a bandpass that changes wavelength over one dimension of the filter to provide a "rainbow" filter effect. This sort of filter produces a spectrum across the camera which enables hyperspectral imaging.
